Place of Origin : China
Brand Name : SYMG
Certification : CE ISO
Packaging Details : Package suitable for long distance sea freight
Supply Ability : 1000 Set/Sets per Year
Price : Negotiable
Model Number : VMC1000
MOQ : 1 Set
Delivery Time : 30-45 days
Product name : VMC1000 Vertical Machining Center 4 axis
Worktable dimensions : 1200x500mm
T-slot sizes : 18x5mm
Max. load allowed : 600kg
X/Y/Z-axis travel : 1000/610/650mm
Max. distance from spindle nose to worktable : 800mm
Min. distance from spindle nose to worktable : 150mm
Spindle speed : 8000r/min
Main motor power : 11/15kw
Tool quantity : 24pcs

Product Description:
Product Features:
1,Classical Structure Design
◆ Super wide beveled bed
◆ Split cover of Y-axis
◆ Multistage filtered chain plate chip conveyo
2,New Update and Improvemer
◆ Improved the thermal stability of lead screw
◆ Improved the seal class of cover
◆ Reduced the thermal deformation of headstock
3,High Configuration, Wide Applicability
◆ Large machining range
◆ Standard chain plate chip conveyor
◆ 11/15 kw main motor
Product Details:

| Item | Unit | VMC 1100B | |
| Capacity | X axis travel | mm | 1100 |
| Y axis travel | mm | 610 | |
| Z axis travel | mm | 650 | |
| Spindle nose to table surface | mm | 150-800 | |
| Worktable | Table size (L×W) | mm | 1300×610 |
| Max load on the table | kg | 1000 | |
| T-slot size | mm | 18×5 | |
| Spindle | Spindle speed | r/min | 10000 |
| spindle shank 7:24 |  | BT40 | |
| Spindle motor | kw | 11/15 | |
| Maximum output torque | N.m | 52.5 | |
| Feed rate | X/Y/Z rapid traverse | M/min | 45/45/30 |
| Feed rate | MM/min | 1-20000 | |
| A.T.C | Tool storage capacity | pc | 24 |
| Maximum tool length | mm | 300 | |
| Tool change time | sec | 2.5 | |
| Accuracy | Positioning accuracy X/Y/Z | mm | 0.010/0.008/0.010 |
| Repeatability positioning X/Y/Z | mm | 0.008/0.006/0.008 | |
| Others | Overall dimensions(L×WxH) | mm | 4200×2480×2950 |
| Net machine weight | kg | 5900 | |
| Total power requirment | KVA | 25 | |
OUR Service:
1. Assemble and debug before delivery
2. Respond within 24 hours and proceed to deal with the problem.
3. 1 year free repair service (no-human damage only).
4. Overall warehousing solution provided



FAQ:
